Linear Bushing Press Fit Type Linear Bushing LMHB Model LMHB
Simple installation through press fitting, An original design with silent, clearance-free motion, Conforms to ISO 10285 Series 1.The LMHB is a linear bushing that is press-fit into a housing. It achieves smooth, silent motion thanks to the spring effect provided by the proprietary curved metal plates designed by THK. The LMHB’s clearance is set by the combination of housing and LM shaft.
Basic load rating N : Basic dynamic load rating 432 to 1462 / Basic static load rating 211 to 786
