High Torque Caged Ball Spline Model SLS
The circumference of the spline nut is shaped in a straight cylinder.Using a key, this model can be secured to the housing, or transmit a torque.
Splineshaftdiameter(mm) : 25,30,40,50,60,70,80,100
Types
Highlight feature tags
- Long-term maintenance free
- Long type
- High torque type
- Cylindrical type
- Solid spline shaft
- Hollow spline shaft
- Long-term maintenance free
- High torque type
- Cylindrical type
- Solid spline shaft
- Hollow spline shaft
basic load ratings(kN) : Basic dynamic load rating 18.2 to 188.2 / Basic static load rating 22.5 to 190.7
Splineshaftdiameter(mm) :
25,30,40,50,60,70,80,100
- Long-term maintenance free
- High torque type
- Long type
- Cylindrical type
- Solid spline shaft
- Hollow spline shaft
basic load ratings(kN) : Basic dynamic load rating 21.7 to 219.8 / Basic static load rating 29.0 to 238.4
Splineshaftdiameter(mm) :
25,30,40,50,60,70,80,100
Detailed information for each model number
Dimensional drawing/Dimensional table
