Full-Ball Type LM Guide Actuator Model KR Compact Series KR15
A series of various types are available from 1 mm to 25 mm in ball screw lead.
Types
Highlight feature tags
- Long block (LM Guide actuator)
- Long block (LM Guide actuator)
LM guide unit basic load ratings(N) : Basic dynamic load rating 1930 / Basic static load rating 3450
- Long block (LM Guide actuator)
LM guide unit basic load ratings(N) : Basic dynamic load rating 1930 / Basic static load rating 3450
- Long block (LM Guide actuator)
LM guide unit basic load ratings(N) : Basic dynamic load rating 1930 / Basic static load rating 3450
- Long block (LM Guide actuator)
LM guide unit basic load ratings(N) : Basic dynamic load rating 1930 / Basic static load rating 3450
Detailed information for each model number
Toggle chart
- Models KR15-A/KR15-B Without Cover, Direct Motor Coupling
- Models KR15-A/KR15-B With Cover, Direct Motor Coupling
- Models KR15-A/KR15-B Without Cover, Motor Wrap
- Models KR15-A/KR15-B With Cover, Motor Wrap
