Linear Bushing Flange-less Type Models LM-GA/LM-GA-AJ/LM-GA-OP
Metal Retainer Type
Basic load rating N : Basic dynamic load rating 206 to 16400 / Basic static load rating 265 to 40000
ShaftDiameter(mm) :
6,8,10,12,13,16,20,25,30,35,38,40,50,60,80,100,120
