Linear Bushing Cut Flange Model LMCH-L
As work pieces can be mounted around the center of the nut, the load can be distributed and spaced evenly on either side of the flange.Ideal for making the stroke even in both directions.
Basic load rating N : Basic dynamic load rating 324 to 1560 / Basic static load rating 529 to 3140
Shaft Diameter (mm) :
6,8,10,12,13,16,20,25
