LM Roller Model LRU Model LRU
Since this model does not require a groove on the mounting surface, man-hours for machining can be reduced. By screwing bolts into four holes on the raceway base, it is secured on the mounting surface.
Basic load rating kN : Basic dynamic load rating 22.1 to 478 / Basic static load rating 42.5 to 807
