High Torque Type Ball Spline High Torque Model LBS
The most compact type with a straight cylindrical spline nut. When transmitting a torque, a key is driven into the body.The outer surface of the spline nut is provided with anti-carbonation treatment.
Splineshaftdiameter(mm) : 15,20,25,30,40,50,70,85,100
Types
Highlight feature tags
- High torque type
- Cylindrical type
- Solid spline shaft
- Hollow spline shaft
- High torque type
- Cylindrical type
- Solid spline shaft
- Hollow spline shaft
basic load ratings(kN) : Basic dynamic load rating 4.4 to 126 / Basic static load rating 8.4 to 237
Splineshaftdiameter(mm) :
15,20,25,30,40,50,70,85,100
Detailed information for each model number
Dimensional drawing/Dimensional table
