Medium Torque Type Ball Spline Medium Torque Model LT
The most compact type with a straight cylindrical spline nut. When transmitting a torque, a key is driven into the body.
Splineshaftdiameter(mm) : 4,5,6,8,10,13,16,20,25,30,40,50,60,80,100
Types
Highlight feature tags
- Medium torque type
- Cylindrical type
- Solid spline shaft
- Hollow spline shaft
- Medium torque type
- Cylindrical type
- Solid spline shaft
- Hollow spline shaft
basic load ratings(kN) : Basic dynamic load rating 0.44 to 136.2 / Basic static load rating 0.61 to 195
Splineshaftdiameter(mm) :
4,5,6,8,10,13,16,20,25,30,40,50,60,80,100
Detailed information for each model number
Dimensional drawing/Dimensional table
