Rotary Ball Spline with Support Bearing Rotary Model LTR-V

This lightweight, compact unit-type ball spline features support bearings that are directly integrated with the outer surface of the LT-X spline nut.

  • Lightweight
  • Compact
  • Rotary and linear motions
  • Rotary type
  • With support bearing
  • Solid spline shaft
  • Hollow spline shaft

Spline shaft diameter (mm) : 16,20,25

Types

Copy item link
Add item to favorites

Highlight feature tags

  • Lightweight
  • Compact
  • Rotary and linear motions
  • Rotary type
  • With support bearing
  • Solid spline shaft
  • Hollow spline shaft
Model LTR-V
  • Lightweight
  • Compact
  • Rotary and linear motions
  • Rotary type
  • With support bearing
  • Solid spline shaft
  • Hollow spline shaft

basic load ratings(kN) : Basic dynamic load rating 8.4 to 15.9 / Basic static load rating 13.4 to 26.2
Spline shaft diameter (mm) : 16,20,25

Features

Copy item link
Add item to favorites

Compact

Copy item link
Add item to favorites

The Model LTR-V is more compact than the previous Model LTR-A because it uses a Model LT-X for the ball spline.

Unit: mm

Model No.

Outer diameter of support (D)

Outer diameter of flange (D1)

Pulley mount (D6)

Compared to the previous product

Compared to the previous product

Compared to the previous product

Previous LTR 16A 48 13% smaller 64 16% smaller 36 10% smaller
LTR 16V 42 54 32.5
Previous LTR 20A 56 14% smaller 72 11% smaller 43.5 17% smaller
LTR 20V 48 64 36
Previous LTR 25A 66 15% smaller 86 16% smaller 52 16% smaller
LTR 25V 56 72 43.5

Lightweight

Copy item link
Add item to favorites

The Model LTR-V is more lightweight than the previous Model LTR-A because it uses a Model LT-X for the ball spline.

High Rigidity

Copy item link
Add item to favorites

The support bearing uses a 45° contact angle that is resistant to moment loads.

Linear and rotary mechanisms

Copy item link
Add item to favorites

Ball splines can transmit torque with one shaft, enabling operations that combine linear motion and rotation.
