Spherical Plain Bearing Model SB Model SB
The most popular type of Spherical Plain Bearing in Japan, model SB has wide spherical contact areas and is used as a bearing for heavy loads. The outer ring is split at two points, enabling the inner ring to be accommodated.
Basic load rating kN : Basic dynamic load rating 118 to 507 / Basic static load rating 2940 to 12600
