Models SKR33-A/SKR33-B Without Cover, Direct Motor Coupling
  • Long block (LM Guide actuator)

LM guide unit basic load ratings(N) : Basic dynamic load rating 17000 / Basic static load rating 20400

Models SKR33-A/SKR33-B With Cover, Direct Motor Coupling
  • Long block (LM Guide actuator)

LM guide unit basic load ratings(N) : Basic dynamic load rating 17000 / Basic static load rating 20400

Models SKR33-A/SKR33-B Without Cover, Motor Wrap
  • Long block (LM Guide actuator)

LM guide unit basic load ratings(N) : Basic dynamic load rating 17000 / Basic static load rating 20400

Models SKR33-A/SKR33-B With Cover, Motor Wrap
  • Long block (LM Guide actuator)

LM guide unit basic load ratings(N) : Basic dynamic load rating 17000 / Basic static load rating 20400

Models SKR33-C/SKR33-D Without Cover, Direct Motor Coupling
  • Short block (LM Guide actuator)

LM guide unit basic load ratings(N) : Basic dynamic load rating 11300 / Basic static load rating 11500

Models SKR33-C/SKR33-D With Cover, Direct Motor Coupling
  • Short block (LM Guide actuator)

LM guide unit basic load ratings(N) : Basic dynamic load rating 11300 / Basic static load rating 11500

Models SKR33-C/SKR33-D Without Cover, Motor Wrap
  • Short block (LM Guide actuator)

LM guide unit basic load ratings(N) : Basic dynamic load rating 11300 / Basic static load rating 11500

Models SKR33-C/SKR33-D With Cover, Motor Wrap
  • Short block (LM Guide actuator)

LM guide unit basic load ratings(N) : Basic dynamic load rating 11300 / Basic static load rating 11500
