Notes on Ordering

Note that the number of items that constitute one set diff ers depending on the type of LM guide. Check the sample model number confi gurations and the accompanying notes.

● Sample LM Guide Orders

● Sample Model HR Orders

● Sample Model GSR and GSR-R Orders

● Sample Cross LM Guide Orders
(SCR, CSR, and MX)

● Sample Model HMG Orders

• Note) When ordering Model HMG, attach a reference diagram clearly showing the positioning of the LM block and LM rail.

When placing an order, be sure to let THK know the mounting orientation and the exact position on each LM block where the grease nipple or the piping joint should be attached.
For the mounting orientation and the lubrication, see the mounting orientation and the lubrication , respectively.

The supported options diff er depending on the model number. Check the available options when ordering.
See options

Where a high degree of precision is required, limits apply to the maximum manufactured lengths for LM rails. In such situations, contact THK.
